Bonnet & Spindles
|
|
Loading, please wait...-
Celestial Lever Bib / Pillar Bonnet & Rapid Action Spindle
SKU: CL2003
Use the Finish Code drop-down menu on the product page to calculate the price in various metal finishes.
Celestial Lever Bib / Pillar Bonnet & Rapid Action Spindle
Specify in Order Notes if Hot or Cold Required.
Turning direction diagram available in FAQ Section.
A = 52mm
B = 25mm
Installation & servicing instructions for Rapid Action® spindles are supplied with the tapware but are also available for download here. Learn More
Ex GST: AUD $82.32 Inc GST: AUD $90.55 -
Celestial Lever Wall Bonnet & Rapid Action Spindle
SKU: CL2005
Celestial Lever Wall Bonnet & Rapid Action Spindle
Specify in Order Notes if Hot or Cold Required.
Turning direction diagram available in FAQ Section.
A = 79mm
B = 44mm
(Please note this spindle is also used for the Forward Bowl Sink Set underassembly, as more height is required than the Basin/Vanity spindle).
Installation & servicing instructions for Rapid Action® spindles are supplied with the tapware but are also available for download here.
This bonnet & spindle is only supplied in Raw Brass as it is not visible when installed. Learn More
Ex GST: AUD $82.32 Inc GST: AUD $90.55 -
Celestial Lever Wall Bonnet & Rapid Action Spindle with 15mm Extension of Handle Height
SKU: CL2007
Celestial Lever Wall Bonnet & Rapid Action Spindle with 15mm Extension of Handle Height
Specify in Order Notes if Hot or Cold Required.
Turning direction diagram available in FAQ Section.
A = 94mm
B = 44mm
The extended bonnet & spindle can help deal with situations where the breech is mounted deeper inside the wall. Depending on the situation you may also need to add a Trouble Ring to the wall flange, these are separate items and are additional cost.
Installation & servicing instructions for Rapid Action® spindles are supplied with the tapware but are also available for download here.
This bonnet & spindle is only supplied in Raw Brass as it is not visible when installed. Learn More
Ex GST: AUD $89.38 Inc GST: AUD $98.32 -
Celestial Lever Basin & Vanity Bonnet & Rapid Action Spindle
SKU: CL2006
Celestial Lever Basin & Vanity Bonnet & Rapid Action Spindle
Specify in Order Notes if Hot or Cold Required.
Turning direction diagram available in FAQ Section.
A = 70mm
B = 37mm
Installation & servicing instructions for Rapid Action® spindles are supplied with the tapware but are also available for download here.
This bonnet & spindle is only supplied in Raw Brass as it is not visible when installed. Learn More
Ex GST: AUD $82.32 Inc GST: AUD $90.55 -
Torrens Flared Lever Bib / Pillar Bonnet & Rapid Action Spindle
SKU: TF2503
Use the Finish Code drop-down menu on the product page to calculate the price in various metal finishes.
Torrens Flared Lever Bib / Pillar Bonnet & Rapid Action Spindle
Specify in Order Notes if Hot or Cold Required.
Turning direction diagram available in FAQ Section.
A = 52mm
B = 25mm
Installation & servicing instructions for Rapid Action® spindles are supplied with the tapware but are also available for download here. Learn More
Ex GST: AUD $82.32 Inc GST: AUD $90.55 -
Torrens Flared Lever Basin & Vanity Bonnet & Rapid Action Spindle
SKU: TF2502
Torrens Flared Lever Basin & Vanity Bonnet & Rapid Action Spindle
Specify in Order Notes if Hot or Cold Required.
Turning direction diagram available in FAQ Section.
A = 70mm
B = 37mm
Installation & servicing instructions for Rapid Action® spindles are supplied with the tapware but are also available for download here.
This bonnet & spindle is only supplied in Raw Brass as it is not visible when installed. Learn More
Ex GST: AUD $82.32 Inc GST: AUD $90.55 -
Torrens Capstan Bib / Pillar Bonnet & Rapid Action Spindle
SKU: TC2503
Use the Finish Code drop-down menu on the product page to calculate the price in various metal finishes.
Torrens Capstan Bib / Pillar Bonnet & Rapid Action Spindle
Torrens Capstan spindles turn the same direction for hot and cold.
Turning direction diagram available in FAQ Section.
A = 52mm
B = 25mm
Installation & servicing instructions for Rapid Action® spindles are supplied with the tapware but are also available for download here. Learn More
Ex GST: AUD $82.32 Inc GST: AUD $90.55 -
Torrens Capstan Wall Bonnet & Rapid Action Spindle
SKU: TC2505
Torrens Capstan Wall Bonnet & Rapid Action Spindle
Torrens Capstan spindles turn the same direction for hot and cold.
Turning direction diagram available in FAQ Section.
A = 79mm
B = 44mm
(Please note this spindle is also used for the Forward Bowl Sink Set underassembly, as more height is required than the Basin/Vanity spindle).
Installation & servicing instructions for Rapid Action® spindles are supplied with the tapware but are also available for download here.
This bonnet & spindle is only supplied in Raw Brass as it is not visible when installed. Learn More
Ex GST: AUD $82.32 Inc GST: AUD $90.55 -
Torrens Capstan Basin & Vanity Bonnet & Rapid Action Spindle
SKU: TC2502
Torrens Capstan Basin & Vanity Bonnet & Rapid Action Spindle
Torrens Capstan spindles turn the same direction for hot and cold.
Turning direction diagram available in FAQ Section.
A = 70mm
B = 37mm
Installation & servicing instructions for Rapid Action® spindles are supplied with the tapware but are also available for download here.
This bonnet & spindle is only supplied in Raw Brass as it is not visible when installed. Learn More
Ex GST: AUD $82.32 Inc GST: AUD $90.55 -
Torrens Lever Bib / Pillar Bonnet & Rapid Action Spindle
SKU: TL2503
Use the Finish Code drop-down menu on the product page to calculate the price in various metal finishes.
Torrens Lever Bib / Pillar Bonnet & Rapid Action Spindle
Specify in Order Notes if Hot or Cold Required.
Turning direction diagram available in FAQ Section.
A = 52mm
B = 25mm
Installation & servicing instructions for Rapid Action® spindles are supplied with the tapware but are also available for download here. Learn More
Ex GST: AUD $82.32 Inc GST: AUD $90.55 -
Torrens Lever Wall Bonnet & Rapid Action Spindle
SKU: TL2505
Torrens Lever Wall Bonnet & Rapid Action Spindle
Specify in Order Notes if Hot or Cold Required.
Turning direction diagram available in FAQ Section.
A = 79mm
B = 44mm
(Please note this spindle is also used for the Forward Bowl Sink Set underassembly, as more height is required than the Basin/Vanity spindle).
Installation & servicing instructions for Rapid Action® spindles are supplied with the tapware but are also available for download here.
This bonnet & spindle is only supplied in Raw Brass as it is not visible when installed. Learn More
Ex GST: AUD $82.32 Inc GST: AUD $90.55 -
Torrens Lever Basin & Vanity Bonnet & Rapid Action Spindle
SKU: TL2502
Torrens Lever Basin & Vanity Bonnet & Rapid Action Spindle
Specify in Order Notes if Hot or Cold Required.
Turning direction diagram available in FAQ Section.
A = 70mm
B = 37mm
Installation & servicing instructions for Rapid Action® spindles are supplied with the tapware but are also available for download here.
This bonnet & spindle is only supplied in Raw Brass as it is not visible when installed. Learn More
Ex GST: AUD $82.32 Inc GST: AUD $90.55 -
Deep Seat Raw Brass Spindle Extension (40mm Long)
SKU: PA1532RB
This extension is usually only suitable for basin taps with normal jumper valves.
Should not be used with our Rapid Action sets.*
Should not be used on the wall taps (wall top assemblies).*
These extensions are designed to allow for being cut down at the time of installation to suit the depth required.
If you would like us to machine down the extension piece to a specific length before sending we can do this for you. Learn More
Ex GST: AUD $29.48 Inc GST: AUD $32.43 -
Bonnet Thread Extension (15 BSP) (Adds 15mm to Bonnet Thread) [Raw Brass]
SKU: PA1178RB
These extensions are designed to help counteract deep seats in walls by allowing more thread for the flange to screw on to.
These are suitable for extending standard action wall taps (wall top assemblies). The tap you require this extension for should be noted to CB when ordering.
If the breech is too deep in the wall you may need a combination of this component and a top assembly with a longer spindle to provide a satisfactory resolution. Please see the relevant spares section for suitable spindles. Extended bonnets & spindles are supplied with a bonnet thread extension piece.
Depending on the situation you may also need to add Trouble Rings to the wall flanges which are separate items and additional cost. Learn More
Ex GST: AUD $15.39 Inc GST: AUD $16.93 -
Bonnet Thread Extension (5/8 BSP) (Adds 15mm to Bonnet Thread) [Raw Brass]
SKU: PA8280RB
These extensions are designed to help counteract deep seats in walls by allowing more thread for the flange to screw on to.
These are suitable for extending Rapid Action wall taps (wall top assemblies). The tap you require this extension for should be noted to CB when ordering.
If the breech is too deep in the wall you may need a combination of this component and a top assembly with a longer spindle to provide a satisfactory resolution. Please see the relevant spares section for suitable spindles. Extended bonnets & spindles are supplied with a bonnet thread extension piece.
Depending on the situation you may also need to add Trouble Rings to the wall flanges which are separate items and additional cost. Learn More
Ex GST: AUD $15.39 Inc GST: AUD $16.93
